In this paper, we analyse the performance of a silicon nano-opto-electro-mechanical system (NOEMS) applied as an optical modulator, based on a suspended slot waveguide driven by electrostatic forces. The analysis is carried out with the help of the finite element analysis (FEA) method involving the influences from Casimir force, optical force and electrostatic force. The performance of the. The rib waveguide region to the slot-waveguide region. One of the most critical parameters for an accumulation type modulator is the insulating layer thickness (t ox) of the MOS-capacitor. Of course, there are several other parameters which also directly or indirectly influence the device performance, such as.

• Share

• Get Citation
  Copy Citation Text

  Abhijeet Phatak, Zhenzhou Cheng, Changyuan Qin, and Keisuke Goda, 'Design of electro-optic modulators based on graphene-on-silicon slot waveguides,' Opt. Lett. 41, 2501-2504 (2016)

  Export Citation

Abstract

We present a graphene-on-silicon (GoS) suspended vertical slot waveguide. By changing the Fermi level of graphene, the variation in the effective refractive index (RI) of the waveguide is a factor of two larger than that in the traditional GoS rib waveguide. The improvement is due to the light-intensity enhancement and the poor confinement of the optical mode in the slot nanostructure. We design Mach–Zehnder interferometer (MZI) and microring modulators based on the GoS suspended vertical slot waveguide. Our calculations show that the modulators can be energy-efficient and footprint-compact due to the large phase shift of the propagating mode in the waveguide after applying a gate voltage on the graphene. Fabrication of our design is easy and CMOS-compatible. It paves the way for chip-integrated electronic-RI modulators.
